Gearhead

Parallel Gearhead, Worm Gearhead and Inter-decimal Gearhead are available to be attached to the motor of gear type shaft of DKM possess the wide range of gear ratio from 2:1 to 360:1.

Parallel Gearhead
  • Frame Size: 60/70/80/90mm
  • Gear Reduction Ratio
  • 6GBD( )MH 3 / 3.6 / 5 / 6 / 7.5 / 9 / 10 / 12.5 / 15 / 18 / 20 / 25 / 30 / 36 / 40 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180 / 200 / 250
  • 7GBK( )BMH 3 / 3.6 / 6 / 7.5 / 9 / 12.5 / 15 / 18 / 25 / 30 / 36 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180
  • 8GBK( )BH 3 / 3.6 / 5 / 6 / 7.5 / 9 / 12.5 / 15 / 18 / 25 / 30 / 36 / 40 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180 / 200 / 250 / 300 / 360
  • 9GBK( )BH 2 / 3 / 3.6 / 5 / 6 / 7.5 / 9 / 10 / 12.5 / 15 / 18 / 25 / 30 / 36 / 40 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180
  • 9PBK( )BH 2 / 3 / 3.6 / 5 / 6 / 7.5 / 9 / 12.5 / 15 / 18 / 20 / 25 / 30 / 36 / 40 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180
  • 9PFK( )BH 2 / 3 / 3.6 / 5 / 6 / 7.5 / 9 / 12.5 / 15 / 18 / 20 / 25 / 30 / 36 / 40 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180
  • 9HBK( )BH 3 / 3.6 / 6 / 9 / 12.5 / 15 / 18 / 20 / 25 / 30 / 36 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180
  • 9HFK( )BH 3 / 3.6 / 6 / 9 / 12.5 / 15 / 18 / 20 / 25 / 30 / 36 / 50 / 60 / 75 / 90 / 100 / 120 / 150 / 180

General Box Type
(GB Type)

Powerful Box Type
(PB Type)

Powerful Flange Type
(PF Type)

High Powerful Box Type
(HB Type)

High Powerful Box Type
(HB Type)

Worm Gearhead
Worm Gearheads allow the motor to be installed at the right or left axis of equipment such as conveyor belts. Worm Solid Type and Worm Hollow Type are available.

  • Frame Size
    Worm Solid Type: 80/90mm
    Worm Hollow Type: 90mm
  • Gear Reduction Ratio
    8WD( )BL/BR/BRL 10 / 12 / 15 / 18 / 25 / 30 / 36 / 50 / 60
    9WD( )BL/BR/BRL 10 / 12 / 15 / 18 / 25 / 30 / 36 / 50 / 60
    9WHD( ) 7.5 / 10 / 15 / 20 / 25 / 30 / 40 / 50 / 60 / 80

Worm Solid Type
(Direction of Output shaft: Left)

Worm Solid Type
(Direction of Output shaft: Right)

Worm Solid Type
(Direction of Output shaft:
Bi-directional)

Worm Hollow Type

Inter-Decimal Gearhead
In case of requiring high gear ratio that cannot be generated by single gearhead, X10 Inter-Decimal Gearhead is used with general gearhead. In this case only
speed will reduce by 10:1 without torque increasing.
